Bracket 30 × 30
Material: Bracket: Die-cast zinc, uncoated and silver powder coated.
Cap: Black plastic (PA)
Mounting kit: Galvanised steel
Mounting material:
2× M6 slot 6 slot nuts with step
2× M6 × 14 screw (DIN 7380)
Cap: Black plastic (PA)
Mounting kit: Galvanised steel
Mounting material:
2× M6 slot 6 slot nuts with step
2× M6 × 14 screw (DIN 7380)
Ladda ner PDF (all data)
Generating PDF
+
Lägg till i PDF-katalog
| Designation | Select all | Lead Time * | Description | System | ESD | CAD | Compare | |
|---|---|---|---|---|---|---|---|---|
|
|
/storage/148851059F0A14F83C4FD9708B29D4629F93B6E4E8346BACE61F0728E19D5FCA/a1ec19a3441647269ad947eb8a7cfb88/STEP/media/c6b8abc83a494d06bba53119024a6ee7/CAD_PZ5001_Bracket30x30_Rollco.STEP | 2 | Bracket 30 × 30 | 30 - Slot 6 | - |
|
||
|
|
/storage/5683C1C85E65647442CA4CCBC793DAD861EFCA1C08A825EF441EE035FC64DB8A/465d8537b5834a82b21c8ee01f8cb051/stp/media/e9d951558df2467cb335d23b41b51ee5/CAD_PZ5002_Bracket30x30_Rollco.stp | 1 | Bracket 30 × 30 with mounting material and ABDK | 30 - Slot 6 | - |
|
||
|
|
/storage/2F31B2D8D580FE207CFDA4CAB4793A88F0D788ADDACC216AAD777EA7269D6D24/a2b27ad6e9b24d4982815f6746f88ec6/STEP/media/674738d5475f4417a079fd0c5e2b317b/CAD_PZ5003_Bracket30x30_Rollco.STEP | 2 | Bracket 30 × 30 silver powder coated with mounting material and ABDK | 30 - Slot 6 | Yes |
|
||
|
|
2 | Cap 30 × 30 | 30 - Slot 6 | - |
|
*Green: Normally in stock, contact us for current status. Blue: Contact us for delivery time.
